| MOQ: | 1 |
| Price: | USD |
| Standard Packaging: | Carton Package |
| Supply Capacity: | 1000 units per month |
Specification:
| Temperature Accuracy | ±0.2℃ |
| Temperature uniformity | +0.25℃ |
| Temperature Input Range | At room temperatureto 99℃ |
| Rate of temperature change | heating rate >6℃/s;cooling rate >4℃/s |
| Light life | ≥ 100,000 hours |
| Fluorescence channel | 4 channels |
| Samples per instrument | 2×8 Wells |
| Reaction volume range | 10-100ul,0.2ml |
| Hardware parameters | With touch screen,the experimental process can be viewed in real With touch screen,the experimental process can be viewed in real time;The device supports connecting to the cloud service platfom,a time;The device supports connecting to the cloud service platfom,and can realize functions such as automatic data transmission and nd can realize functions such as automatic data transmission and remote consulting |
| Communication module | USB,Wifi The device can be connected with a code scanning gun and input sample information |
| Physical parameters | Small size,easy to carry;External |
| 373×330×145mm(L×W×H) | |
| Weight | 4kg |
PCR principle:
The essence of PCR technology is nucleic acid amplification in vitro, heat to uncoil double stranded DNA, hybridize primer with template DNA at annealing temperature, extend primer in the presence of Taq DNA polymerase, dNTPs, Mg2+ and suitable pH buffer, repeat the process of "denaturation → annealing → primer extension" to 25 ~ 40 cycles. Exponentially expand the nucleic acid copy number in the sample to be tested.
Micgene 162/164 Real-time fluorescence quantitative PCR analyzer:
Remark:
Small and exquisite:
Easy to carry, vehicle-mounted, small in size, light in weight, and easy to carry;
Steady light path:
Fixed optical path, no moving parts, means no optical alignment or calibration after moving;
Strong light source:
Each channel has a separate high-intensity LED excitation source, using separate emission filters and detectors;
Warm up fast:
Use magnetic induction technology to achieve heating and forced airflow cooling, faster heating and cooling time;
Temperature control standard:
Rotating aluminum rotors have unmatched temperature uniformity in both dynamic and static operation;
Product detail:
|
|
